SALE

Mitutoyo Standard Indicator, Lug Back, ISO Type, 10mm, 0,01mm 2046A

Original price was: £32.00.Current price is: £9.60.

SKU: 2046A_A Category: Tag:

Standard Type, 10 mm Range, 0,01 mm Graduation
This is a standard dial indicator. It offers you the following benefits:

  • Bezel clamp and lifting lever (optional) can be attached to either right or left side. They can be easily installed and removed without tools.
  • No through screw holes on the frame as well as the use of an O-ring prevents water or oil penetration.

Features

Digital/Analog: Analog
Inch-Metric: Metric
Functions: ISO type
Delivered: With certificate of inspection
Range: 10 mm
Range
per rev.:		 1 mm
Dial reading: ±0-100
Graduation: 0.01 mm
Measuring force: 0,4 – 1,4 N
MPE any 1/10
revolution:		 5 µm
MPE any 1/2
revolution:		 9 µm
MPE any 1
revolution:		 10 µm
MPE measuring range: 13 µm
H MPE
(Hysteresis):		 3 µm
R MPE
(Repeatability):		 3 µm
Mass: 144 g
Stem: 8 mm
Contact point: Carbide tipped, thread: M 2.5 x 0.45 mm
Continuous dial: Yes
