| Scale Type: | AT715 |
|---|---|
| Resolution: | 0,001 / 0,005 (switchable via Counter) |
| Length (mm): | 400 |
| Manufacturer Part Number: | 539-807N |
| Brand: | Mitutoyo |
| Additional Information: | Cable length: 3.5mEffective Length: 400 mmMass: 1 kgMax. drive speed: 50 m/minMeasuring method: Electromagnetic induction systemOld Article number: 539-807RSignal period: 20 |
The Mitutoyo AT715 linear scale features ABSOLUTE® electromagnetic induction technology for high-accuracy position feedback without homing. With IP67 protection, it resists coolant and dust, making it ideal for harsh machine tool environments. It offers 0.001mm/0.005mm resolution (switchable), ±5μm to ±7μm accuracy, and speeds up to 50 m/min. Its compact design allows flexible mounting, especially on small lathes, while compatibility with KA counters ensures seamless integration into precision systems.
Features & Benefits:
•Electromagnetic induction system provides absolute position detection—no homing required at power-on
•IP67 protection ensures excellent resistance to dust, coolant, and water ingress
•Resolution: switchable between 0.005mm and 0.001mm via compatible KA counters
•Accuracy: ±5μm for lengths 100–500mm / ±7μm for lengths 600–1800mm
•Measuring range: 100mm to 1800mm
•Max response speed: 50 m/min
•Mounting flexibility: scale can be installed in two orientations, ideal for tight or awkward spaces
•Sliding force: less than 5N for smooth motion
•Compatible displays: KA series counters
•Ideal for: X-axis installation on small lathes and other compact machine tools
